Scope of Application
Truck mounted hotbox reclaimer is a professional integrated thermal regenerative maintenance equipment for asphalt roads. It can be used to mix and heat both old asphalt mixed materials and new asphalt mixed materials. The machine consists of asphalt heating system, emulsified asphalt spray system, auto feeding system, auxiliary loading/unloading system and power system. Therefore, it is an ideal machine for provides hot asphalt mixed materials for the damaged road conveniently and rapidly./p>
| Machine Data | |
| Dimension (length×width×height) | 4440×1988×1915 mm |
| Weight | 3500 kg |
| Drum volume | 1000 L |
| Continuous heating time | 20-25 min |
| Temperature control range | 0-300 ºC |
| Heating manner of drum | Diesel burner → hot air circulation heating |
| Volume of asphalt heating tank | 150 L |
| Heating manner | Diesel burner → heat transfer oil → asphalt |
| Heating temperature | 140-170°C |
| ปั๊มส่งแอสฟัลต์ | 1m3/h |
| Volume of emulsified asphalt tank | 10 L |
| Generating unit | KOHLER gasoline generator, 13 kW, 380/220V, electronic start. |
| Auto feed manner | Reducer gear motor → Feed guide rail → Feed silo → Dump |
| Single feed | 0.1m³ (bulk asphalt mixed materials) |
| Lift system | Hydraulic oil cylinder + supports (four groups) |
| Lift height scope | 1-1.5 m |
| Alarming unit | Alarming indicator lamp (dual arrows) |
